24" Width Grip Strut Walkway Safety Grating Anti Skid Aluminum Metal Sheet For Platform Walkways

Grip Strut Walkway Steps Safety Grating Anti Skid Aluminum Metal Sheet

Product Overview
Grip Strut is a form of galvanized steel that is grated to provide a safe walking and working environment. Both the bottom and the top part of the grip strut are manufactured in such a way that there is resistance on all sides. For any slippery working environment, a grip strut is a must-have.

Grip Strut is the industry leader in safety grating. A versatile, one-piece metal plank, Grip Strut is manufactured with unique diamond shaped openings and formed side channels. Maximum, multi-directional slip resistance is provided by a heavily serrated, diamond matrix walking surface that enhances workplace safety. With approximately 35% open area, fluids and ice easily pass through the grating. Non-serrated surfaces are available upon special request.

Benefits of Grip Strut include

• Maximum slip resistance
• Easy to fabricate and install
• Ideal for industrial applications
• Low maintenance
• Widths & Depths

Grip Strut planks has standard widths include

2 Diamond (4 ¾” wide)
3 Diamond (7” wide)
4 Diamond (9-1/2” wide)
5 Diamond (11-3/4” wide)
8 Diamond (18-3/4” wide)
10 Diamond (24” wide)
Standard channel depths include 1-1/2”, 2”, 2-1/2”, and 3”.

Stock lengths of 10’ and 12’ are readily available and custom lengths are available on special order.

Materials
Grip Strut planks are available in the following materials:

Pre-galvanized steel, ASTM A924 G90, 14 or 12 gauge
HRPO uncoated steel, ASTM A1011, 14 or 12 gauge
5052-H32 aluminum, ASTM B209, 12 gauge (.080) or 10 gauge (.100)
304 or 316L stainless steel, 16 gauge

Additional Grip Strut Products
In addition to plank grating, the distinct benefits of the Grip Strut surface are also available in OSHA compliant walkway channels, stair treads, ladder rungs, floor resurfacing materials, and Heavy Duty Grip Strut. For further details.

Company Information


Hebei Zhuote Wire Mesh products Co., Ltd. is located in the "Hometown of Chinese silk screen" - Anping County, Hebei Province, is a modern steel grid production enterprise in the northern region with a very large scale, the company set production, sales, research and development and one.The company's products include trench cover, tree pool cover, inserted steel grid and other steel grid (grid) products, and steel mesh, guardrail net products.We can also according to the needs of users, the production of large heavy bearing steel lattice plate, special steel lattice plate and other products.To provide design scheme and cost control for different working environment, bearing capacity, span, shape and color as well as cost.The company has a steel grid automatic production line, a galvanized production line, nearly 50 technical workers, research and development personnel, the products are exported to Europe and The United States and Southeast Asia, quality and cheap service thoughtful, welcome new and old customers to buy.All products are in accordance with The Chinese YB/T4001-2007 standard, or the United States ANSI/NAAMM(MBG53193), the United Kingdom BS4592-11995 and Australia AS1657-88 standard products are widely used in petroleum, chemical, port, power, transportation, paper making, medicine, steel, food, municipal, real estate, manufacturing and other fields.Hangjin always adheres to the guiding ideology of "survival by quality and efficiency by management".From contract signing, product production to delivery, we fully implement ISO9001 quality management system, ERP system and 5S management, and wholeheartedly provide customers with the best quality products.

FAQ
Q: Quotation time
A:We usually quote with 12 hours after getting inquiry .
Q:How can I get a sample to check your quality ?
A:We are very glad to post you samples before order .
Q:Can you do the design for us ?
A:Yes , We have a professional team with rich experience in design .
Q:What is the lead time for mass production ?
A:It depends on the order quantity and the season you place the order . The lead time is about 7-10days !
