Galvanized steel driveway grating floor serrated steel grating

Galvanized steel driveway grating floor serrated steel grating

Steel bar grating is one of our main grating products,also know as press weld steel bar grating.Due to the extremely strong and durable for all the bearing application,whice become the most popular grating in the markets.The stability makes them have a much higher performance in the application.

1>material:carbon steel or stainless steel

2>cross bar pitches:maybe 24-200mm,of which 50mm,76mm and 100mm are recommended.

3>Steel grating is made by the world first-class equipment,which can arrange the bearing bar and cross bar in longitude and latitude order to certain distance.cross bar is pressed into the bearing bar by high tension resistance weldingring which is controlled by computer.so we can produce high quality gratings with firm welding,smooth surface and high strength.

4>Surface process of steel grating:Types:hot-dipped galvanized,electro-galvanized ,spraying brushing. 95% people choose hot-galvanized because its anti-acid and alkali corrosion capacity range is from PH6 to PH12.5,a stable protective film will be formed on the zinc surface.it has good anti-corrosive property.

5>Attractive appearance:Simple outline.silver colour and modern.

6>Optimum water draining:Water leakage area reaches 83.3%,which is more than two times larger than that of cast iron.

7>Hot-dip galvanizing:Good antirust performance,maintenance free and replacement free.

8>Design of preventing theft:The cover is connected with the frame by gemel,which ensures protection against theft,safety and convenient opening.

Features:
1) Bearing bar specification: 20 x 3 to 100 x 6
2) Bearing bar pitch: 12.5, 15, 30, 40, 60mm etc, also be according to client's requirement and 30, 40, 60mm are recommended
3) Cross bar pitch: 38, 50, 76, 100mm, also be according to client's requirement and 50, 100mm are recommended
4) Material: Mild steel or stainless steel
5) Surface treatment: Untreated, painted or hot-DIP galvanized

Package Type:
Standard Dimensions Building Materials Flat Type Steel Grating Packing Method:
1. Bandage and Paperboard: Generally applies to neat steel plate;
2. Screw Locking Method: Use 4 screw rods through the aperture of the steel grid, for high strength;
3. Steel Pallet: Traditional export packing.

Project case
