Tooth Hot Dip Galvanized Steel Grating Lattice Plate Construction Stair Foot Pedal
| Place of Origin | Hebei |
|---|---|
| Brand Name | Zhuote |
| Certification | ISO9001-2015 |
| Model Number | 303/45/100 |
| Minimum Order Quantity | 100 piece |
| Price | Can discuss |
| Packaging Details | Steel belt packaging |
| Delivery Time | 11 work days |
| Payment Terms | L/C, T/T |
| Supply Ability | 1000 Square meters/day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Material | Steel, Q235, SS316 | Surface Treatment | Hot Dipped Galvanized, Galvanized, Painting, Hot Dip Galvanized |
|---|---|---|---|
| Application | Floor, Platform, Stair Tread, Steel Structure, Bridge | Type | Plain Bar Grating, Serrated Bar Grating, Plain, Serrated, I Bar Grating |
| Thickness | 3-6mm | Color | Silver, Silver Or As Your Requirement, Green, Black, White |
| High Light | 3mm hot dip galvanized steel grating,ss316 hot dip galvanized steel grating,serrated bar hot dip galvanized grating |
||
Product Description
Hot dip galvanized tooth steel lattice plate construction stair foot pedal
Product Description
Steel grating is made of flat steel in a certain spacing and cross bars (twisted square steel, square steel, round steel, flat steel, etc.), and is welded into a square with a square in the middle. A kind of steel product of lattice, steel grating is mainly used for gutter cover, steel structure platform board, steel ladder step board, etc. The crossbar is generally twisted square steel. Steel grating is generally made of carbon steel, and the surface is hot-dip galvanized, which can prevent oxidation. It can also be made of stainless steel. The steel grating has the properties of ventilation, lighting, heat dissipation, non-slip and explosion-proof.
Specification
a. Material: Q235B, A36, SS400, S235JR, SS304, SS316, SS304L, SS316L
b. Dimension: Thickness: 3mm-10mm
c. Flat bar pitch: 30mm,40mm,50mm,60mm
d. Twisted bar pitch: 50mm, 100mm
e. Length: Regular as 3m per piece
f. Material: A36 or equivalent material, SS304, SS316
g. Advantage: light weight, heavy load capacity, easy installation
h. Surface treatment standard: GB/T13192, BS EN ISO 1461-2009
i. Technical standard: YB/T 4001.1-2007 (GB), ANSI/NAAMM(MBG531-88) ( ANSI), BS4592-1987, AS1657-1985, DIN24537-1-2006
j. Surface treatment: Hot DIP galvanized, painting, acid washing and polishing for stainless steel grating.
k. Cross bar type: Round bar, I bar, twisted bar, twisted square bar. Flat bar type: Plain or serrated
b. Dimension: Thickness: 3mm-10mm
c. Flat bar pitch: 30mm,40mm,50mm,60mm
d. Twisted bar pitch: 50mm, 100mm
e. Length: Regular as 3m per piece
f. Material: A36 or equivalent material, SS304, SS316
g. Advantage: light weight, heavy load capacity, easy installation
h. Surface treatment standard: GB/T13192, BS EN ISO 1461-2009
i. Technical standard: YB/T 4001.1-2007 (GB), ANSI/NAAMM(MBG531-88) ( ANSI), BS4592-1987, AS1657-1985, DIN24537-1-2006
j. Surface treatment: Hot DIP galvanized, painting, acid washing and polishing for stainless steel grating.
k. Cross bar type: Round bar, I bar, twisted bar, twisted square bar. Flat bar type: Plain or serrated
Application
- Grating floor mat
- Working platform
- Grating floor panels
- Grating manhole cover
- Grating ditch cover
- Stairs, stairs Grating
- Traffic works, highways, factories, farms, urban areas
- Oil and gas industries, cement, ships...
Packing & Shipping
Standard Grating Packing Method:
1. Bandage and Paperboard: Generally applies to neat steel plate;
2. Screw Locking Method: Use 4 screw rods through the aperture of the steel grid, for high strength;
3. Steel Pallet: Traditional export packing.
Walkway Grating has great features like water and air ventilation, it’s easy to install and uninstall, suitable for wheel
equipment.
As a steel walkway grating supplier, we carry metal walkway grating products along with common accessories.
|
Item
|
Description
|
|
|
1
|
Bearing Bar
|
25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10,100x10mm etc; I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc US standard: 1'x3/16', 1 1/4'x3/16', 1 1/2'x3/16', 1'x1/4', 1 1/4'x1/4', 1 1/2'x1/4', 1'x1/8', 1 1/4'x1/8', 1 1/2'x1/8' etc. |
|
2
|
Bearing Bar Pitch
|
12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1,
40, 41.25, 60, 80mm etc US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc. |
|
3
|
Twisted Cross Bar Pitch
|
38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2' & 4' etc
|
|
4
|
Material Grade
|
ASTM A36, A1011, A569, Q235, S275JR, SS304,
Mild steel & Low carbon steel, etc |
|
5
|
Surface Treatment
|
Black, self colour, hot dip galvanized, painted, spray coating
|
|
6
|
Grating Style
|
Plain / Smooth, Serrated /teeth, I bar, serrated I bar
|
|
7
|
Standard
|
China: YB/T 4001.1-2007,
USA: ANSI/NAAMM(MBG531-88), UK: BS4592-1987, Australia: AS1657-1985, Japan:JIS |
|
8
|
Application
|
China: YB/T 4001.1-2007,
USA: ANSI/NAAMM(MBG531-88), UK: BS4592-1987, Australia: AS1657-1985, Japan:JIS |
Company philosophy
We believes in building and retaining strong client relationships based upon reliability, flexibility and design. Our primary
objectives are to achieve high standards of excellence with the ability to offer a bespoke service to individual clients.
Technical Support
The Technical Department is able to recommend the most appropriate grating or louvre for a particular project before preparing a panel layout which will make the most economical use of the selected material. Our practice is to work closely with the architect from concept to final design, preparing CAD drawings and advising on secondary steelwork, alternative fixing methods and loading specifications.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: 30% T/T in advance ,balance before shippment.
