Large output, wide application range and long life of steel grating
| Place of Origin | Anping China |
|---|---|
| Brand Name | TT |
| Certification | ISO9001:2015 |
| Model Number | TT-2 |
| Minimum Order Quantity | 50m2 |
| Price | Negotiable |
| Packaging Details | Packing Suitable For Export,Also Depend On Customar Decide |
| Delivery Time | 3-5Days,Also Depend On the Quantity |
| Payment Terms | L/C, T/T |
| Supply Ability | 500M2 Per Day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Application | Industrial | Bearing Bar Pitch | 30mm, 40mm, 50mm, Etc |
|---|---|---|---|
| Grating Standard | YB/T4001.1-2007 | Product Category | Industrial Steel Grating |
| Bearing Bar Type | Serrated | Product Name | Customized Thickness And Bar Spacing Industrial Steel Grating |
| Load Bearing Capacity | Heavy Duty | Texture | Stainless Steel |
Product Description
| product technology The production of steel grid plate mainly has two kinds of machine pressure welding and manual production. Machine pressure welding using high voltage resistance pressure welding machine, through strong electric welding power and liquid pressure to press the transverse rod into the flat steel, to ensure that the solder joint is strong, stable and strong. Handmade, on the other hand, is relatively flexible and suitable for various special needs.  |
product material Raw materials of steel grid plate are: flat steel, twist steel, pattern plate.
The steel grid plate is an open steel member which is composed of bearing flat steel and cross bar according to certain spacing and fixed by welding or pressure lock. The transverse bar is generally made of twisted square steel, round steel or flat steel, and the material is divided into carbon steel and stainless steel.
Production method of steel grid plate:
The pressure welded steel grid plate is made of load flat steel and cross bar arranged according to certain spacing longitude and latitude, using 200 tons of hydraulic resistance welding automatic equipment to weld into the original plate, through cutting, opening, packaging and other processes.
Load flat steel spacing: the center distance between two adjacent load flat steel, commonly used 30MM, 40MM two.
Bar spacing: The center spacing of two adjacent bars is usually 50MM and 100MM.
Specification:
| 25x3mm catwalk steel grating | |
| TYPE | STEEL GRATING,ATYPIA/FAN-SHAPED STEEL GRATING,SERRATED GRATING, FLAT STEEL GRATING,SS GRATING,GLASS STEEL GRATING,STEP GRATING,DITCH COVERING GRATING |
| RAW MATERIAL | I-TYPE STEEL FLAT,FLAT,ROUND BAR,SERRATED STEEL FLAT,TWIST STEEL,CHECKERED PLATE,SIDE PLATE,ETC |
| MATERIAL | CARBON STEEL(Q235B),STAINLESS STEEL(201/304/316),GLASS STEEL,ETC |
| SPECIFICATION |
FLAT STEEL:20*3/20*4/20*5/25*3/25*5/30*3/30*4/30*5/32*3/32*5… ROUND BAR: 5/6/8/10MM(DIAMETER) |
| APERTURE | 30*50/30*100/40*50/40*100... 50*50/40*40/30*30(CUTTAGE GRATING) |
| SURFACE | P(PAINTING),G(HOT DIP GALVANIZED,COLD GALVANIZING),U(UNTREATED) |
| PROCESS | CUTTING-PUNCHING-WELDING-SURFACE TREATMENT |
| PACKING | STEEL BELT PACKING,BULK |
| USAGE | SERRATED GRATING SUITABLE FOR WET/SLIPPERY PLACE,OFFSHORE OIL PLATFORM,SS GRATING MAINLY USDED FOR POWER PLANT PROJECTS,CHEMICAL PLANTS,OIL REFINERIES,SHIPBUILDING,PAPER MILLS,PHARMACEUTICAL,ROAD,AIRPORT,ETC |
| SPECIAL SHAPE AND SIZE CAN BE CUSTOMIZED AS PER CUSTOMER'S REQUEST | |
