Long Lasting Corrosion Resistant Thorn Rope For Metal Building Materials

  • Long Lasting Corrosion Resistant Thorn Rope For Metal Building Materials
  • Long Lasting Corrosion Resistant Thorn Rope For Metal Building Materials
  • Long Lasting Corrosion Resistant Thorn Rope For Metal Building Materials
  • Long Lasting Corrosion Resistant Thorn Rope For Metal Building Materials
  • Long Lasting Corrosion Resistant Thorn Rope For Metal Building Materials
Place of Origin CHINA
Brand Name ZHUOTE
Certification BSCI, TUV, ISO,etc
Model Number YW04
Minimum Order Quantity 1000meters-1499meters
Price $10
Packaging Details Plastic inner and outer knitting, inner plastic outer hemp, carton, pallet Single gross weight: 10.000 kg Single package size: 65X65X8 cm
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 1000meters+7days

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Surface Treatment Galvanized Type Barbed Wire Coil
Material Low Carbon Steel Q195 Sample Availiable
Corrosion Well Corrosion Resistant Barb Distance 75mm~150mm
Barb Length 10mm-65mm Application Highway Isolation Protection
Packaging Details Plastic Inner And Outer Knitting, Inner Plastic Outer Hemp, Carton, Pallet
Highlight

Long lasting Thorn Rope

,

Corrosion Resistant Thorn Rope

,

Metal Building Materials Thorn Rope
Leave a Message
Product Description

When you need to get serious about security, Concertina Razor Wire is the best solution. It is relatively inexpensive, but viciously effective. Concertina razor Wire around the perimeter is enough to deter any wouldbe vandal, robber or saboteur. Razor Wire is made of a corrosion resistant galvanized steel cutting ribbon wrapped around a core of galvanized spring steel wire. It's impossible to cut without highly specialized tools, and even then it's a slow, dangerous job. Concertina Razor Wire is a long lasting and very effective barrier, known and trusted by security professionals.

Reference Type Number Thickness(mm) Wire Diameter(mm) Barb Length(mm) Barb Width(mm) Barb spacing(mm)
BTO-10 0.5±0.05 2.5±0.1 10±1 13±1 26±1
BTO-12 0.5±0.05 2.5±0.1 12±1 15±1 26±1
BTO-18 0.5±0.05 2.5±0.1 18±1 15±1 33±1
BTO-22 0.5±0.05 2.5±0.1 22±1 15±1 34±1
BTO-28 0.5±0.05 2.5 28 15 45±1
BTO-30 0.5±0.05 2.5 30 18 45±1
BTO-60 0.6±0.05 2.5±0.1 60±2 32±1 100±2
BTO-65 0.6±0.05 2.5±0.1 65 21±1 101±2
Outside Diameter No.of Loops Standard Length Per Coil Type Notes
450mm 33 8m CBT-65 Single Coil
500mm 41 10m CBT-65 Single Coil
700mm 41 10m CBT-65 Single Coil
960mm 53 13m CBT-65 Single Coil
500mm 102 16m BTO-10,15,22 Cross Type
600mm 86 14m BTO-10,15,22 Cross Type
700mm 72 12m BTO-10,15,22 Cross Type
800mm 64 10m BTO-10,15,22 Cross Type
900mm 52 9m BTO-10,15,22 Cross Type

Long Lasting Corrosion Resistant Thorn Rope For Metal Building Materials 0Long Lasting Corrosion Resistant Thorn Rope For Metal Building Materials 1

We have a complete set of quality control system, with which every product has been strictly inspected. Thus, we can provide customers with excellent products and services.

With reliable quality and reasonable prices, we win extensive public praise and credit in the international market. We believe, with support of our customers, through continuous endeavor, Hebei Yongwei Metal Produce Co., Ltd. will make more progress, and make contributions to the development of China wire mesh industry.
