Rust-Proof Steel Grating: A Reliable Option for Outdoor and Marine Applications

Place of Origin Anping China
Brand Name TT
Certification ISO9001:2015
Model Number TT-2
Minimum Order Quantity 50m2
Price Negotiable
Packaging Details Packing Suitable For Export,Also Depend On Customar Decide
Delivery Time 3-5Days,Also Depend On the Quantity
Payment Terms L/C, T/T
Supply Ability 500M2 Per Day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Application Industrial Bearing Bar Pitch 30mm, 40mm, 50mm, Etc
Grating Standard YB/T4001.1-2007 Product Category Industrial Steel Grating
Bearing Bar Type Serrated Product Name Customized Thickness And Bar Spacing Industrial Steel Grating
Load Bearing Capacity Heavy Duty Texture Stainless Steel
Leave a Message
Product Description

Dimensions
Material thickness: Common thickness of 2mm, 3mm, 4mm, 5mm and so on. Different thicknesses of steel grids have different bearing capacities and are suitable for different application scenarios.

Size: Width is common 100mm, 150mm, 200mm, 250mm, 300mm, etc. The length is made according to customer requirements, and the general length is between 1 meter and 6 meters. The dimensions of steel grids must be determined according to the actual application scenario.

Grid plate spacing: usually millimeters (mm) as a unit, such as 25mm, 30mm, 40mm and so on. The spacing affects the bearing capacity and anti-skid performance of the steel grid.

Load grade: According to the carrying capacity is divided into different grades, such as A15, B125, C250, etc., representing different carrying capacity. The selection must be based on the load requirements of actual applications.Rust-Proof Steel Grating: A Reliable Option for Outdoor and Marine Applications 0Rust-Proof Steel Grating: A Reliable Option for Outdoor and Marine Applications 1

item Galvanized Stainless Fence Drainage Channel Serrated Steel Bar Steel Grating
Warranty More than 5 years
Surface galvanized
Style Plain sheet,Serrated sheet,I type sheet
Usage Industrial platform, Corridor laying, Ditch cover plate, Fence, etc
Bearing bar pitch Custom:12.5-90mm Routine use:20mm 30mm 40mm
Cross bar pitch Custom:22-100mm Routine use:50mm 100mm
Thickness Custom:3-10mm Routine use:3mm 4mm 5mm
Weld way Automatic pressure resistance welding





Name Steel Grating
Bearing Bar 25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10---100x10mm etc
I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc
US standard: 1''x3/16'', 1 1/4''x3/16'', 1 1/2''x3/16'', 1''x1/4'', 1 1/4''x1/4'', 1 1/2''x1/4'', 1''x1/8'', 1 1/4''x1/8'', 1
1/2''x1/8'' etc
Bearing Bar Pitch 12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc
US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.
Twisted Cross Bar Pitch 38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2'' & 4'' etc
Material Grade ASTM A36, A1011, A569, Q235, S275JR, SS304, SS400,
Mild steel & Low carbon steel, etc
Surface Treatment Black, self colour, hot dip galvanized, painted, spray coating
Grating Style Plain / Smooth, Serrated /teeth, I bar, serrated I bar
Standard China: YB/T 4001.1-2007, USA: ANSI/NAAMM(MBG531-88),
UK: BS4592-1987, Australia: AS1657-1985,
Germany: DIN24537-1-2006, Japan :JIS
