19w4 Steel Grating Heavy Duty Outdoor Walkway Platform Hot Dip Galvanized

Place of Origin Hebei
Brand Name Zhuote
Certification ISO9001-2015
Model Number 325/30/100
Minimum Order Quantity 70
Price Can discuss
Packaging Details Steel belt packaging
Delivery Time 11-14 work days
Payment Terms L/C, T/T
Supply Ability 1250 Square meters/day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Application Protecting Mesh, Filters, Screen, Decoration, Etc Type Perforated Mesh, Welded Mesh, Expanded Mesh
Material Stainless Steel Wire, Aluminum, Galvanized Steel Wire, Nickel, Etc Weave Style Perforated, Plain Weave, Punch, 60 Degree
Color Silver, Black, White, Golden, Gold Thickness 0.5mm, 0.6/0.8/1.0/1.2/1.5/2.0/2.5/3.0/4.0/5.0, Or As Request., 0.1mm- 15mm, 3mm
High Light

19w4 steel grating heavy duty

,

walkway steel grating heavy duty

,

serrated bar heavy duty metal grate

Leave a Message
Product Description

19-W-4 Outdoor walkway platform for Hot dip galvanized heavy duty welded steel grating



Introduction:
Metal Bar Grating is the workhorse of the industrial flooring market and has served industry for decades. Strong and durable with an exceptional strength-to-weight ratio, metal bar grating can be easily fabricated to nearly any configuration.
Manufactured by assembling a series of equally spaced metal bars to connecting cross members, bar grating is available in three popular materials; mild carbon steel, 6000 series aluminum and 300 series stainless steels.

Welded Grating
Economical design ideal for most industrial applications. Manufactured by welding the bearing bar/cross bar intersection, typically with automated forge welding equipment. Available in carbon steel and stainless steel.


Swage Locked Grating
Popular for the manufacture of aluminum, stainless steel and close mesh gratings. Cross bars are inserted into pre-punched holes in the bearing bars and then hydraulically deformed to lock the bars in place.


Dovetail Pressure Locked Grating
Assembled by inserting pre-punched bearing and cross bars into an "eggcrate" configuration and deforming the cross bars under intense hydraulic pressure. Available in all materials and ideal for many architectural and ornamental applications.




Product name *Steel grating
Material

*Mild steel (Carbon steel)

*stainless steel 304, SS316

Material standard

*USA:ASTM A36

*UK:BS4360

*Australia:AS3679

*China:Q235

Bearing bar type

*Smooth/flat bar

*serrated/toothed bar

*Smooth I bar

*Serrated I bar

Bearing bar thickness *2mm to 10mm, 3mm and 5mm recommended
Bearing bar pitch *12.5-30mm/40mm/50mm/60mm/80mm/90up,30and40mm recommended
Bearing bar specification

*flat bar and serrated bar 20*3,20*5,25*3,25*5,30*3,30*4,30*5,32*3,32*5,35*3,35*5,40*3,40*5,

45*5,50*3,50*5,55*5,60*5,65*5,70*6,75*6,75*8,80*8,90*8,100*8,

120*8,130*8,150*8

*I-section bar 25*5*3,32*5*3,38*5*3,44*5*3,50*5*3,50*7*4,55*7*4,60*7*4,

65*7*4,75*7*4

Cross bar *5*5mm,6*6mm,8*8mm
Cross bar pitch *30mm,38mm,50mm,76mm,100mm,50mm and 100mm recommended
Surface treatment

*Hot dipped galvanized

*Untreated(self-color)

*Painted

HDG standard

*ASTM A123

*BS729

*AS1650

Grating Standard

*AS1657-2013

*BS4592-2006

*ANSI/NAAMM(MBG531-88)



19w4 Steel Grating Heavy Duty Outdoor Walkway Platform Hot Dip Galvanized 019w4 Steel Grating Heavy Duty Outdoor Walkway Platform Hot Dip Galvanized 1



Hebei Zhuote Wire Mesh Products Co., Ltd. as a manufacturer which is specializing in producing and exporting a complete series of steel grating and other wire mesh products. Our steel grating goods have various of kinds with different material, the mainly products are high, middle and low - carbon steel, stainless steel, aluminum steel grating. And have varous of style, for example platform steel grating, special steel grating, serrated steel grating, high duty steel grating, press locked steel grating and so on. With the development of our steel grating business, we have gradually improved our manufacturing expertise and engineering construction capabilities. As well as we also produce other wire mesh products, such as Fence, Expanded Metal Mesh, Reinforced Steel Mesh, Gabion Mesh, Chain link mesh and so on. The series of wire mesh are export to the Europe market, America, Middle East, Russia, Australia, Africa countries. We do custom manufacture and can supply a high quality OEM service for clients.



FAQ
Q: Are you a manufacturer?
A:Yes, we have been in providing the professional products in wire mesh field for 10 years.

Q:Why choose us?
A: Save Time,Save Cost and Safety!Each of our customers proved this!

Q: How about the payment terms?
A:We usually use the T/T,L/C,D/P, Western Union.Trade assurance service optional for over $100 order. (100% guaranteed transaction by Alibaba ). L/C optional if over $50k. Paypal optional if below $500.

Q: How about the delivery time?
A:Usually within 15- 20 days,customized order may need longer time.

Q:Can you offer free sample?
A:Yes, but usually the customer need to pay the freight.We'll send back the courier charge if you make an order.
